Automatic tension controller

Category：

Specializing in the research, development, production, and sales of tension controllers, web guiding controllers, tension detectors, magnetic powder brakes, magnetic powder clutches, and other industrial automation products. Expert in industrial motion control and web control.

E-mail:

sales@wxkcon.com

Consult Now

Product Details

Features
The automatic tension controller adopts a number of internationally advanced technologies; a dedicated microprocessor, a high-speed 18-bit AD converter, anti-interference automatic recovery technology, and a PID algorithm without overshoot, thus achieving constant tension control. It is widely used in printing, packaging, papermaking, textile, cable and other industries that require precise tension measurement and control. According to the different input signals, it is divided into:
● Fully automatic tension controller KTC828 type
The input signal of the tension control system can be selected from:
1. Current or voltage output (mA or mV) from the tension detector - Fully automatic type
2. Output signal (0-9V) from encoder or proximity switch - Semi-automatic type

Specifications

Working power input	AC220V 100W
Working power output	DC10V, tension detector power supply
Analog input signal	Two-channel tension detector signal input
Analog output signal	Control output DC0~10V for controlling inverters, servo amplifiers, etc. Control output DC0~24V for controlling DC24V, current below 4A magnetic powder (electromagnetic) clutches \| brakes, etc.
Digital input signal	Each digital quantity uses a photoelectric isolation circuit input. All digital inputs are only DIO DIA DIB
Operating ambient temperature	-10-40℃
Operating ambient humidity	35~85%RH (no condensation)
Operating environment	No corrosiveness, no flammable gas, no conductive dust, less dust
Grounding	Class D grounding (prohibited to share grounding with high-voltage power lines)
